Arc and Square and Type Rectangular Copper Tube Crystallizer

Henan Shengmiao Instrument Co., Ltd.
  • Application：Continuous Casting
  • Warranty：6 Months for Continuous Casting Crystallizer
  • After-sales Service：Provided for Continuous Casting Crystallizer
  • Material：Copper
  • Demoulding：Pull Core
  • Surface Treatment：Coat-Plating

Base Info

  • Specification：according to request for copper mould tube
  • Transport Package：by Woonden Box for Copper Mould Tube
  • Condition：New
  • Customized：Customized
  • Certification：ISO 9001 SGS
  • Mould Life：500,000-1,000,000 shots
  • Average Wall Thickness：>3mm
  • Using Hardness：>HRC45
  • Model NO.：CMT001
  • Trademark：Shengmiao
  • Origin：China
  • HS Code：8454902100
  • Production Capacity：50, 000pieces,Year

Description

MaterialCu-DHPCu - AgCu - Cr - ZrHigh Phosphorus Deoxidized CopperCu - Ag ( Cu - 0.1Ag )Cu-Cr-Zr ( Cu - 0.6 Cr - 0.15 Zr )PropertiesNormal Deoxidized copperThrough the addition of about 0.1% silver, strength is significantly enhanced with no loss in thermal conductivityCr and Zr precipitation hardening provides this alloy with high strengh, high resistance to heat, and thermal conductivityMelting point1083°C1083°C1078°CCoefficient of thermal expansion at 20°C1.68x10-51.68x10-51.70x10-5Thermal340 W/(m·K)377 W/(m·K)325 W/(m·K)Recrystallization330°C370°C700°CHardness at 20°CMin. 85 HBMin. 90 HBMin. 120 HB Arc and Square and Type Rectangular Copper Tube CrystallizerArc and Square and Type Rectangular Copper Tube CrystallizerWelcome contact us freely about Arc and square and type rectangular copper tube crystallizer
