High Strength Crystallizer for Molten Steel Cooling Copper Mold Tubes

Henan Shengmiao Instrument Co., Ltd.
  • Demoulding：Pull Core
  • Material：Copper
  • Application：Continuous Casting
  • Warranty：6 Months
  • After-sales Service：Provided
  • Surface Treatment：Coat-Plating

Base Info

  • Transport Package：by Woonden Box
  • Condition：New
  • Customized：Customized
  • Certification：ISO 9001
  • Mould Life：500,000-1,000,000 shots
  • Average Wall Thickness：>3mm
  • Using Hardness：>HRC45
  • Model NO.：CMT001
  • Specification：according to request
  • Trademark：Shengmiao
  • Origin：China
  • HS Code：8454209000
  • Production Capacity：50, 000pieces,Year

Description

MaterialCu-DHPCu - AgCu - Cr - ZrHigh Phosphorus Deoxidized CopperCu - Ag ( Cu - 0.1Ag )Cu-Cr-Zr ( Cu - 0.6 Cr - 0.15 Zr )PropertiesNormal Deoxidized copperThrough the addition of about 0.1% silver, strength is significantly enhanced with no loss in thermal conductivityCr and Zr precipitation hardening provides this alloy with high strengh, high resistance to heat, and thermal conductivityMelting point1083°C1083°C1078°CCoefficient of thermal expansion at 20°C1.68x10-51.68x10-51.70x10-5Thermal340 W/(m·K)377 W/(m·K)325 W/(m·K)Recrystallization330°C370°C700°CHardness at 20°CMin. 85 HBMin. 90 HBMin. 120 HB  Raw Material of High strength crystallizer for molten steel cooling
To provide Square & Rectangular & Round copper mould pipe crystallizer tube with optimal physical and mechanical properties to customers' specifications, mould tube products are supplied of the following materials:
  1. Cu-DHP: Normally used for mould tubes section size below 180x180mm and round tubes below Dia.150mm.
   2. Cu-Ag: Normally used for mould tube section size above 180x180mm and round tubes above Dia.150mm
   3. Cu-Cr-Zr: Normally used for beam blank mould tubes

These materials have different levels of hardness and thermal conductivities. We are highly experienced in choosing proper materials to meet the specific demands in heat resistance and thermal conductivities of customers' applications.
About ShengmiaoUpgrade Cuag Material High Quality Copper Mould Tube for CCM
Founded in 1992, Henan Shengmiao Instrument Co., Ltd. is one of the China's leading supplier of copper mould tube and plate for continuous casting industry. With over 20 years of expertise in metallurgy industry of copper and copper alloys, the company is committed to research & development, and providing a range of high quality, innovative, cost-effective copper mould tube products and solutions.

Possessing advanced manufacturing equipments and cutting-edge technology for mechanical and Eelectro-plating processing, in order to meet customer's requirement, the company designs and develops cooper mould tube and plate according to DIN, ASTM, EN, JIS standard. Providing diverse lines of the products backed by expert R&D technical support, we develop closer customer relationships and taking on a larger role in the total supply and manufacturing chain. The diverse products include copper mould tubes and copper mould plates.

Our ISO 9001:2015 certification registered production facilities are emblematic of Shengmiao's ongoing commitment to quality and sustainability in the manufacture of these products. The company maintains stringent quality processes and standards in the industry to ensure an effective Quality Management System, continual improvements, and excellence in customer satisfaction.

Being approved by international well-known inspection institutions such as SGS, OMIC, IKA, ISQI, COTECNA, our products have been exported to Europe, Asia, Africa, South America and Middle Eastern countries, which enjoys good reputation.

As an influential and responsible supplier, we are able to provide our customers with more thoughtful services and technical support. To ensure long-term customer satisfaction, we offer comprehensive support for copper mould over their whole life cycle.
Upgrade Cuag Material High Quality Copper Mould Tube for CCM
Customer Visiting for High strength crystallizer for molten steel coolingUpgrade Cuag Material High Quality Copper Mould Tube for CCMWe can provide this High strength crystallizer for molten steel cooling as per the customer's specific requirements.
