• Heat Treatment：Nitriding, etc
• Mould Base：S50c
• Mould Operating Mode：Automatically by CNC
• Mould Cooling System：by Experienced Designer
• Mould Design Software：Ug, Proe, Solidworks CAD, Ect
• Mould Standard：Dme
• Mould Runner System：Hot or Cold Runner System
• Mould Quality Control：Professional QC
• Size：According to Customers Requirement
• Customized：Customized
• Standard：DME
• Certification：ISO
• Installation：Fixed
• Design Software：UG
• Runner：Hot Runner
• Model NO.：JSL-T171225-4
• Transport Package：High Quality Wooden Case
• Specification：DME
• Trademark：JSL MOULD
• Origin：Huangyan, Taizhou, China
• HS Code：8480719090
• Production Capacity：500sets,Year

Mold description:

High quality washing machine mould

Purchase order:

Customer to confirm order

Invoice:

Proforma invoice

Payment:

50% down payment of the full PI

Parts design

Modifications for better make mold

Mold design:

For good appearance of the parts and mold run well

Structure:

2 plates mold

Inserts:

Where need for easy maintain

Runner:

cold runner

Gate:

sub gate

Shrinkage:

shrinkage abs 0.5%

Slider:

Drive by cylinder

Ejection:

By ejectors and lifters

Confirmation:

Mold design

Order steel:

High quality mold steel will be used

Rough machining

Before fine machine

Heat treatment

nitride

Hardness:

to 38-42HRC

Fine machine:

High speed CNC

Fine machine:

Engraving machining

Fine machine

EDM

Assembly:

Adjust for final assembly

Surface finish:

polishing

Test:

Mold test with pictures and videos

Polish:

Good polish

Samples:

5pcs for checking

Improve:

Improvement after checking samples

Mold cooling line:

support 24hous production

Suitable for:

400T Injection machine

Balance:

50% deposit after approval final samples

Delivery

1-2weeks after confirm final samples

Transport

By sea from Ningbo Port China

Why Us?

1. We make more than 100 washing machine moulds each year and most for foreign customers. So we have most experience and can make good quality control.

2. We have special professional designers and mold makers for washing machine mold after making so many washing machine molds.

3. Many customers cooperate with us more than 7years, some are 10years, and their loyalty shows our honest on mold.

4. Quality is the life of our company. We focus on quality and time control. Every mould machining process will be weekly informed.

5. Trust was built on you know better of us. Believe yourself and choose us won't let you down. Let's try and know you better. You need good washing machine mould supplier, and what we need is a chance to show you who we are and what we can do.
