PPR Plastic Injection Pipe Fitting Mold
Zhejiang Taizhou Huangyan Jingzheng Mould Co., Ltd.- Plastic Material：PPR
- Mould Cavity：Single Cavity
- Surface Finish Process：Polishing
- Shaping Mode：Injection Mould
- Process Combination Type：Single-Process Mode
- Runner：Cold Runner
Base Info
- Trademark：JZ
- Specification：ISO9001-2000
- Transport Package：Woodencase
- Customized：Customized
- Standard：DME
- Certification：ISO
- Installation：Fixed
- Design Software：UG
- Model NO.：JZ
- Origin：China
- HS Code：8480719090
- Production Capacity：1000,Year
Description
Basic Info.
Model NO. JZ Design Software UG Installation Fixed Certification ISO Standard DME Customized Customized Transport Package Woodencase Specification ISO9001-2000 Trademark JZ Origin China HS Code 8480719090 Production Capacity 1000/YearProduct Description
Plastic PPR Mould
High quality with reasonable price, by using Chinese, Korean, Japan, Germany Standard to make moulds.
| Name | Plastic PPR Mould |
| Plastic material | PPR |
| Steel of Cavity & Core | DIN1.2738 |
| Steel of Mouldbase | S50C. LkM standard^ etc |
| Nos of Cavity | 4 |
| Hardness of Cavity & Core | 48-52HRC |
| Hardness of Wear Parts | 55-60HRC |
| Core pulling system | Motor /oil cylinder/ stripping plate, angel pin^ etc |
| Mould Accessories | DME/HASCO Standard ^ |
| Cooling system | In core baffle cooling and in cavity plate chain drilling type cooling |
| Surface finish | Diamond polish, |
| Molding life | 1, 000, 000shots |
| Runner | Cold |
| Delivery time | 60 wrok days |
| Packing | wooden case |
