• Rapid Prototypes：CNC Prototyping
• Acuum Casting Mold：Aluminum Die Casting Mold
• Customized：Customized
• Standard：HASCO
• Certification：TS16949, CE, ISO, FDA
• Installation：Fixed
• Design Software：UG
• Runner：Cold Runner
• Application：Car, Household Appliances, Furniture, Electronic
• Process Combination Type：Platinum Cure Silicone for Tyre Mold Making
• Plastic Material：ABS
• Model NO.：Vacuum Casting Silicon Moulding
• Prototype Mold：Vacuum Casting Mold
• Transport Package：Paper Carton Box
• Specification：silicone vacuum casting
• Trademark：silicone vacuum casting
• Origin：China
• HS Code：8480410010
• Production Capacity：5000PCS,Day

Basic Info.

Model NO. Vacuum Casting Silicon Moulding Plastic Material ABS Process Combination Type Platinum Cure Silicone for Tyre Mold Making Application Car, Household Appliances, Furniture, Electronic Runner Cold Runner Design Software UG Installation Fixed Certification TS16949, CE, ISO, FDA Standard HASCO Customized Customized Acuum Casting Mold Aluminum Die Casting Mold Rapid Prototypes CNC Prototyping Prototype Mold Vacuum Casting Mold Transport Package Paper Carton Box Specification silicone vacuum casting Trademark silicone vacuum casting Origin China HS Code 8480410010 Production Capacity 5000PCS/Day

Product Description

Vacuum casting silicone mold Platinum Cure Silicone for Tyre Mold Making

Basic Info.
Model No.: Vacuum casting silicone mold
Material: Silicone Rubber
Appearance: Liquid
Color: As Request
Export Markets: Global
Additional Info.
Trademark: HongYe silicone rubber
Packing: 20kg/Drum, 200kg/Drum
Standard: RoHS. MSDS. SGS ISO9001: 2000
Origin: Shenzhen China
HS Code: 39100000
Production Capacity: 8 Tons Per Day
Product Description
Platinum cure Silicone For Tyre Mold making

Description of Addition cure silicone for tyre Mold making
HY- E series addition molding silicone is generally named two-components silicone
Rubber, Part A and part B. It features an exceptional fluidity and good operability.
The mixing ratio is 1: 1 (10: 1), mainly be suitable for making molds application.

Typical Applications of Platinum cure silicone for tyre mold making
HY- E series addition molding silicone could be mainly used for making concrete
Stones, wax molds, PU molds, resin molds, gypsum casting, candle molding and
Chocolate, candy and any other FDA food product mold making, prototyping etc.
HY-E620 Silicone Rubberis has been used for years to make tire pattern molds.

Characteristics of Platinum cure silicone for tyre mold making

*low shrinkage (less than 0.1% )
*high tensile and tear strength with high copy times
*easy for operation (mixing ratio at 1: 1 /10: 1)
*very good flow and easy for pouring operation
*Fast and non-shrink cure at room temperature which can be accelerated considerably by the application of heat

Operation instruction of HY-E620 Platinum cure silicone for tyre mold making

1. Pls clear the model and tool totally before operation to prevent cure inhibition.
2. Weigh the two part correctly by electronic weight in two separate container.
3. Mixing the two part in 1: 1/10: 1 and stir part A and part B evenly in 2-3 minutes.
4. And get the mixture for vacuum-pumping for de-air the bubble in around 2-3
Minutes. (If there is no vacuum machine, pls pour the mixture carefully and slowly
Down the side of the mold frame so that less bubbles caused)
5. Enclose the product (the original model) with four plastic plates or wooden plates.
6. Clean your products and brush a layer of release agent(detergent or soap water) on
Your product.
7. Pour the vacuumed mixture into the model frame from the side of the mold frame.



Notice of Platinum cure silicone for tyre mold making

As our E-series silicone is platinum cure silicone, which is very easy to cause
Cure inhibition, so pls do remember thoroughly clean the model and tool before
Operation. Besides, pls avoid the liquid E-series silicone contact or mix with the
Following material, otherwise the silicone won't be cured:
1. Liquid condensation silicone ( condensation silicone not completely cured or organic
Tin compounds )
2. Sulphur, sulfide and sulfur rubber materials.
3. Amine compounds as well as contains the amine materials.
4. Pewter solder flux.


SHELF LIFE of Platinum cure silicone for tyre mold making:
8-10 months when stored under 24° C in original unopened packages.

PACKAGE:
If ratio is 1: 1: Packed in 20kg/pail + 20kg/pail and 200kg/pail + 200kg/pail.
If ratio is 10: 1: Packed in 20kg/pail + 2kg/pail and 200kg/pail + 20kg/pail.

Model	HY-E620#
Appearance	Translucent
Mixing Ratio	1:1
Operating time (Mins 25°C)	20-30
Curing time (Mins 25°C)	2-3h
Hardness (A°)	20±2
Density ( g/cm 3 )	1.08
Viscosity (CS)	6000 ± 2000
Tensile-strength( kgf /cm2 )	25 ± 2
Tear-strength (kgf /cm2 )	20
Elongation-break(%)	380 ± 50
Retractility(%)	≤0.1
