• Transport Package：Wood Package
• Warranty：12 Months
• Quality Control：Test Before Delivery
• Place of Origin：Zhejiang China
• Base Material：38crmoaia,42CrMo
• Brand Name：Pym
• Metal Mould：Die Casting
• Model NO.：T Die
• Specification：T Die
• Trademark：yumin
• Origin：Ruian
• HS Code：8483409000
• Production Capacity：1000piece

Polymer to be processed
PS,PA,PE,PP,ABS,PET
Lamination  thickness
 6-10mm
DIE width
700mm-4000mm  according your need
Lamination  width
700mm-4000mm  according your need
Lips
flexible and adjustable  45° chock bar
Upper lip can be micro adjusted
Flow channel
Coat hanger
Heating Voltage
380v
Raw material of the die
P20/5CrNiMo/2738 from GERMANY
Heating unit
Heating bars made of stainless steel
Cable connection:
Close connecting with protection cover
Screws
 High strength at 12.9 grade
Polishing
Lips and surface of flowing: 0.02-0.03(μm),
Other surfaces: 0.03-0.04(μm).
Electroplating
Lips and surface of flowing harden treatment by
 chrome plating. Plating thickness: 0.04-0.05mm
Hardness: 60-65Rockwellc
Other surface thickness: 0.01-0.02mm
Feeding
Square center feeding
Installation
Confirmed by buyer
Payment
50% down payment paid by TT upon order signed
50% to be paid before delivery
Delivery
25 days after down payment.


FAQ:
Q1: What's your biggest concern?

A: Q------qulity more than 20 years' expierence + professional high technology production
Team + strict product inspection = high qulity

P------price large scale production + full set of independent production = reasonable price

Q2: Guarantee time and after-sale?
A: One year guarantee time, after one year, we have professional after-sales department

More question, pls feel free to contact us!
