• Specification：Customized
• Transport Package：Customized
• Service：Customized
• Types：Customized
• Color：Customized
• Size：Customized
• Customized：Customized
• Standard：HASCO
• Certification：TS16949, CE, ISO, FDA
• Installation：Fixed
• Design Software：AutoCAD
• Runner：Hot Runner
• Model NO.：MT
• Trademark：Customized
• Origin：Xiamen, China
• HS Code：3926909090
• Production Capacity：50000PCS Per Month

PM-F0:Non-cosmetic: finish to Protomold discretionPM-F1:Low-cosmetic: most toolmarks removedPM-F2:Non-cosmetic: Protomold discretion, EDM finish and/or toolmarks permissibleSPI-C1:600 grit stone, 10-12 RaPM-T1:Protomold texture, SPI-C1 followed by light bead blastPM-T2:Protomold texture, SPI-C1 followed by medium bead blastSPI-B1:600 grit paper, 2-3 RaSPI-A2:Grade #2 Diamond Buff, 1-2 Ra
*"PM" in the table signifies a surface finish adjusted to fit the quick-turn injection molding process, where SPI (The Society of the Plastics Industry) denotes an industry-standard finish.
Radii
Because Proto Labs employs an automated CNC milling process to make the mold for your parts, some part corners will end up with a radius rather than a sharp edge. This does not usually require a change to the model, but the designer is made aware of these radii before the mold is made.
Ejector pins
Proto Labs' injection molding process uses ejector pins of various sizes to push the plastic part out of the mold after it has solidified. The sizes and arrangement of these pins are selected to minimize the impact on your part design. Ejector pins range in size from 0.063 in. (1.6mm) to 0.5 in. (12.7mm), with sizes larger than 0.063 in. (1.6mm) preferred.
Undercuts
Our molding process supports simple undercuts in your part geometry. Maximum side core dimensions:WidthHeightPull≤ 8.419 in≤ 2.377 in≤ 2.900 in≤ 213.84mm≤60.38mm≤73.66mm
