Customized Plastic Shell/Cover Motorcycle/Auto Spare Parts Plastic Injection Mould

XIAMEN METEOR COMMERCE & TRADE CO., LTD.
  • Application：Car, Household Appliances, Furniture, Commodity, Electronic, Home Use, Hardware
  • Process Combination Type：Single-Process Mode
  • Plastic Material：PA66+GF
  • Mould Cavity：Multi Cavity
  • Shaping Mode：Injection Mould
  • Surface Finish Process：Painting

Base Info

  • Specification：Customized
  • Transport Package：Customized
  • Customized：Customized
  • Standard：HASCO
  • Certification：TS16949, CE, ISO, FDA
  • Installation：Fixed
  • Design Software：AutoCAD
  • Runner：Hot Runner
  • Model NO.：MT
  • Trademark：Customized
  • Origin：Xiamen, China
  • HS Code：3926909090
  • Production Capacity：50000PCS Per Month

Description

PM-F0:Non-cosmetic: finish to Protomold discretionPM-F1:Low-cosmetic: most toolmarks removedPM-F2:Non-cosmetic: Protomold discretion, EDM finish and/or toolmarks permissibleSPI-C1:600 grit stone, 10-12 RaPM-T1:Protomold texture, SPI-C1 followed by light bead blastPM-T2:Protomold texture, SPI-C1 followed by medium bead blastSPI-B1:600 grit paper, 2-3 RaSPI-A2:Grade #2 Diamond Buff, 1-2 Ra
*"PM" in the table signifies a surface finish adjusted to fit the quick-turn injection molding process, where SPI (The Society of the Plastics Industry) denotes an industry-standard finish.WidthHeightPull≤ 8.419 in≤ 2.377 in≤ 2.900 in≤ 213.84mm≤60.38mm≤73.66mm
