• Customized：Customized
• Certification：ISO
• Installation：Fixed
• Design Software：UG
• Runner：Hot Runner
• Model NO.：F04
• HS Code：8480790090
• Production Capacity：180 Sets,Year

Basic Info.

Model NO. F04 Runner Hot Runner Design Software UG Installation Fixed Certification ISO Customized Customized HS Code 8480790090 Production Capacity 180 Sets/Year

Product Description

RootChina established as a professional tools & dies manufacturer in China, provide one-stop solutions for plastics including mould manufacturer, injection molding, assembling and secondary processing services (printing/painting/plating).
Our Service:
1. DFM is provided before mold design.
2. CAE analysis is available if requested, such as Mold flow.
3. Steel certification and heat treat report is provided.
4. Weekly mold progress report with photos available.
5. Mold testing video/2D&3D drawings is provided before shipment.
6. Full dimension inspection report is available.
7. Warranty time: one year.

Our Advantage:
1. With more than 10 year experience in exported mould, especially for automotive moulds & household moulds, certificated by ISO9001:2008
2. Professional marketing engineer & project engineer promoted from mould designer with rich technical knowledge.
3. 2-3days fast response for inquiry, simple or urgent inquiry can be replied in one day.
4. Export about 100sets moulds to USA & Europe every year.
5. In house strict quality control.
6. Fast and on time delivery.
7. All moulds can work automatically.

What do we need for an mould inquiry?
1. Part drawings including 2D&3D
2D drawing indicates plastic material/tolerance/ finish request and so on.
2D drawing format: DWG or DXF file.
3D drawing format: STP/ X_T/ IGES /Solidwork/Proe/UG/CATIA and so on
2. Mould Cavity No:
Mould cavity No. affect price greatly. It depends on how many pcs parts do you want to produce one cycle time, also affect moulded parts price much.
3. Mould Life:
It depends on the volume you need the mould to produce. If the volume is big, recommend to use multiple cavities mould with high quality steel.
4. Cycle Time:
If the volume is big, cycle time affect part price greatly. We can build shorter cycle time tooling and create more value for you.

Facilities List

No	Equipment Name	Brand	Origial Place	Model No:	Working Stroke	Quatity
1	Wire Cutting	Sodick	Japan	AQ600L3	600X400	1
2	Wire Cutting	Sodick	Japan	AQ360LXS	360X250	1
3	Wire Cutting	Fangzheng	China	/	500X450	3
4	EDM	Sodick	Japan	AM30LS	320X250	1
5	EDM	Jingda	Taiwan	D350	350X250	2
6	EDM	Qunji	Taiwan	QJ-345	400X500	2
7	Milling Machine	Xuzheng	Taiwan	/	600X350	6
8	CNC	Youhong	China	S1060	1000X600	3
9	Polishing Machine	Zhunli	Taiwan	618	350X200	4
10	Polishing Machine	Yalida	Taiwan	/	350X200	4
11	Polishing Machine	Dejian	Taiwan	/	300X500	1
12	Cliper	Mitutoyo	Japan	/	200mm	6
13	Micrometer	Mitutoyo	Japan	/	200mm	2
14	Projector	Mitutoyo	Japan	/	300mm	1

The information has been udated by RootChina on 2020-04-01.
